Loveshaw - Carton Sealer - Model - LDX-UTB

Loveshaw - Model - LDX-UTB - Semi-Automatic - Uniform - High-Speed Top and Bottom Belt Drive Carton Sealing Machine

Case Sealing for the Real World

The LDX-UTB Case Sealer is a solution for businesses requiring a state of the art top and bottom drive case taper.  This semi-automatic system is built to handle large runs of uniform cases at high speeds or those applications that require infrequent case size changes.  This sealer effortlessly seals cases from 3.5" to 24.5" in height.

The Little David® LDX-UTB is the latest in a series of industrial grade, high-performance case sealers from Little David®.

Constructed of fully welded tubular steel, this top and bottom drive case sealer is set up to run hard on your production floor.  Its speed, extensive box range, and instant box changeover with self-centering side rails set it apart from competing machines.

This unit incorporates a sealed drive, an internally mounted electrical system.

Ideal for those seeking an alternative to expensive competitor models and labor costs. The LDX-UTB also replaces the tedious task of hand taping cases and the use of unsafe machinery.  This model requires very low maintenance and operates with simple adjustments.

This versatile machine has options available to allow for customization. These options include some of the following: casters, leg adjustments, top squeezers and more. - Configure your machine in options section above.

All PARTS are stocked and available for immediate shipment.  All technical support, service, and machine parts are fully supported by our dedicated technical parts division Machine Parts Toolbox.

Standard Features of the LDX-UTB:

Include:

• HIGH PERFORMANCE

•  This case sealer can process cases 20%-80% faster than the competition, giving you the efficiency you need.

• INDUSTRIAL DESIGN

• Welded tubular steel construction.

• Reinforced critical stress points.l

• Lightweight removable access panels.

• USER-FRIENDLY

• Self-centering side rails and adjustable top drives

• Including movable magnetic control station with start/e-stop button

• Interchangeable top and bottom tape cartridge.

• QUICK/EASY MAINTENANCE

• Easy access to all the motors, electrics, and belts

• Quick and easy maintenance or repairs.

• Tapes cartons from 3.5″ (114mm) to 24.5″ (610mm)

• Can Be ordered for 2" or 3" wide sealing tape

• Plug in operation

• Minimal operator training required

• Sealed drive system

• CaseLocker 60 tape cartridge

This high-performance tape cartridge features positive tape

cutting, light touch rollers, and an adjustment-free design.

It is the safest, strongest tape cartridge in the market, the

CaseLocker™ 60 tape cartridge is a masterpiece of

Loveshaw’s patented engineering innovations.

Reliable Performance Warranty:

• 1 Year all Components*

• 2 Years Gear Reducer

• 3 Years Tape Cartridge*

•  *Moving and wear parts are not included. Other restrictions may apply. Consult with us for details.

Power Requirements:

• 110 Volts, 60 cycle, single phase

•  Note: Other voltages available. Special request on quote for details.

Operating Speed:

• Continuous belt drive

• Standard: 115’ per minute (35.05 m/min.)


• High Speed: 155’ per minute (47.25 m/min.)

• (production rate depends on box size and operator dexterity)

Weight:

• 570.0 lbs (258 kg) uncrated

Machine Dimensions:

• Height: 67-3/8″ (170.9 cm)

• Width: 33-5/8″ (93.4 cm)

• Length: 46-1/4″ (117.5 cm)

Closure Material:

• Pressure sensitive sealing tape

Case Capacity:

Based on use of 2" wide CaseLocker ST® Cartridge

Minimum / Maximum

• Height: *3.5″ ( mm) / Height: 24.5″ ( mm)

• Width: 5-1/2″ ( mm) / Width: 26″ ( mm)

• Length: 6″ ( mm) / Length: ifinite

•  *Minimum height can be reduced to 2.5” with reduced tape tab length

All Loveshaw machines and equipment are proudly made in the USA.
